Digital Meter Kyoritsu 2012R

Masuk untuk melihat harga

Multitester Multimeter Kyoritsu KEW2012R (True RMS)

Brand: Kyoritsu Original
Made in Thailand

Dengan design yang compact produk kyoritsu 2012R dapat ditaruh pada saku kantong baju serta ujung clamp yang terbuka dan kecil sangat memudahkan pengukuran ampere dengan praktis.

Innovative Multimeters with current measurements up to 120A AC/DC

*DC V 600.0mV/6.000/60.00/600.0V (Input impedance: approx. 10M)
1.0%rdg3dgt
* AC V 6.000/60.00/600.0V (Input impedance: approx.10M)
1.5%rdg5dgt (45 - 400Hz)
* DC A 60.00/120.0A
2.0%rdg8dgt (60A)
2.0%rdg5dgt (120A)
* AC A 60.00/120.0A
2.0%rdg5dgt (45 - 65Hz)
* 600.0/6.000/60.00/600.0k/6.000/60.00M
1.0%rdg5dgt (600/6/60/600k)
2.0%rdg5dgt (6M)
3.0%rdg5dgt (60M)
* Continuity buzzer Buzzer sounds below 3525
* Diode test 2V3.0%rdg5dgtOpen-loop voltage: approx. 2.7V
* Capacitance 400.0nF/4.000/40.00F
2.5%rdg10dgt
* Frequency
(AC A) 100/400Hz 0.2%rdg2dgt (100Hz) 0.1%rdg1dgt (400Hz)
(DC A) 100/1000Hz/10/100/300.0kHz 0.2%rdg2dgt (100Hz)
0.1%rdg1dgt (1000Hz/10/100/300.0kHz)
(Input sensitivity
Current: more than 6A
Voltage: more than 6V [- 10kHz]/more than 20V [10k - 300kHz])
* Conductor size 12mm max.
* Applicable standards IEC 61010-1 CAT III 300V, CAT II 600V Pollution degree 2
IEC 61010-031, IEC 61010-2-032, IEC 61326
* Power source R03 (1.5V) 2
* Continuous measuring time:
DCV: approx. 150hours, ACA: approx. 25hours
(Auto power save: approx. 15 minutes)
* Dimensions 128 (L) 92 (W) 27 (D) mm
* Weight 220g approx. (including batteries)
* Included Accessories R03 (1.5V) 2, Instruction manual

Type ini cocok untuk yang mobilitas tinggi yang tidak ingin direpotkan dengan peralatan ukur yang besar namun sangat lengkap, bisa mengukur capasitor + true rms.
